BUSY WEEKEND:DYI Oil Change / De-Rusted & G2'd my rotors / Lowered / Full Pics of all

Reply




Thread Tools Search this Thread Rate Thread Display Modes
  #1
Old 09-19-2010, 07:42 PM
roxboxxx's Avatar
Registered User

Join Date: Mar 2009
Location: NJ
Posts: 926
Rep Power: 58
roxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant future
BUSY WEEKEND:DYI Oil Change / De-Rusted & G2'd my rotors / Lowered / Full Pics of all

BUSY weekend - spent 2 days under my C doing various projects.

1.) OIL CHANGE: I typically pay the stealer $250+ and I figured after all the crap I have done to my C, why not a simple oil change.
Filter, new drain plugs and oil filter wrench all came from suncoast. Mobil1 came from pepboys. For those who have never done it before, total cost is less then $90 wing ***** if you have the tools. See notes above each pic.


2.) BRAKE FIX: De-Rust my once really nice rotors (my fault - I used caliper paint instead of G2 epoxy). Problem solved - see pics.


3.) DROPPED FURTHER: Decided my C was not low enough so I spun the rear KWs all the way down (can't go any further) and dropped the fronts to match. Ride quality is identical to how it was before - handling, def a performance increase.


ENJOY THE PICS:

1. ) OIL CHANGE

> My 5000 lb + C on plastic ramps - YES PLASTIC

Click the image to open in full size.

T50 Torx is needed for the drain plug(s) and 10mm socket to pull down the front plastic shield (NOTE: you only have to remove the front shield - not both.)

Click the image to open in full size.


After the shields are removed, you can see the oil filter housing (removed in this pic) and oil drain plug easily. There is actually a second drain plug at the back of the engine about 12 inches from the first drain plug. When I removed the second one after the first stopped dripping, nothing came out. To me, its a waste to remove the second plug. NOTE - YOU SHOULD REPLACE THE DRAIN PLUGS WITH EVERY OIL CHANGE!! They are made of aluminum and strip very easily.

Click the image to open in full size.

New filter and oil filter housing

Click the image to open in full size.


So here is what my oil looked like after 7K (I Drive my C like a 911)

Click the image to open in full size.


New filter install - You just push it up over the male end, grease the seal around the housing, screw the oil filter housing over the filter and tighten with the wrench.

Click the image to open in full size.



Once everything is tight I filled with 2 Quarts of 0w 40 mobil1 and then checked for leaks (engine off of course). With no leaks noted, I put in the remaining 6 quarts (8 quarts total), start, let run for 15 min, check for leaks. With no leaks noted, I screwed the plastic shields up and called it done.

Overall - piece of cake and a good way to bond with your car.

2.) Rotor rust repair.

A year ago I replaced my rotors, pads & painted my calipers. The full DYI is here: http://www.6speedonline.com/forums/c...s-painted.html

Well, I screwed up and painted the rotor hubs with caliper paint instead of G2 epoxy. The rust came 6 months later and I addressed it all this weekend. This time I used G2

BEFORE:

Click the image to open in full size.


AFTER:

Click the image to open in full size.

3.) Dropped

So while I was under my truck all weekend, I decided to go lower. Here is the results. Can't go any lower than this as the backs are spun all the way down. As I said up top - ride quality is identical, it just handles better now.


Click the image to open in full size.


So that was my weekend - My hands and back are shouting at me now (is it normal to physically see your hands pulse??). Both my truck and me are happy.
Will re-torque all my lug bolts in 100 miles for safety sake.

More projects coming soon.
__________________
Everything I ever did to my pepa in one thread: http://www.6speedonline.com/forums/c...ervations.html

Last edited by roxboxxx; 09-19-2010 at 07:49 PM.
Reply With Quote
  #2
Old 09-19-2010, 08:02 PM
knicks's Avatar
Registered User

Join Date: Jul 2009
Location: Morris Plains, NJ
Posts: 361
Rep Power: 20
knicks will become famous soon enough
I've got the same plastic ramps as you. they work fine for me haha thank you for the detailed write up.
__________________
M3
Reply With Quote
  #3
Old 09-19-2010, 10:19 PM
djantlive's Avatar
Registered User

Join Date: Oct 2004
Location: SFBA
Posts: 6,646
Rep Power: 320
djantlive has a reputation beyond reputedjantlive has a reputation beyond reputedjantlive has a reputation beyond reputedjantlive has a reputation beyond reputedjantlive has a reputation beyond reputedjantlive has a reputation beyond reputedjantlive has a reputation beyond reputedjantlive has a reputation beyond reputedjantlive has a reputation beyond reputedjantlive has a reputation beyond reputedjantlive has a reputation beyond repute
Oil changes are fairly simple even on modern cars. Nothing any one should be afraid of. Good job!
Reply With Quote
  #4
Old 09-20-2010, 08:45 AM
SuncoastParts's Avatar
Basic Sponsor

Join Date: Sep 2004
Location: Sarasota
Age: 34
Posts: 1,532
Rep Power: 92
SuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond reputeSuncoastParts has a reputation beyond repute
Thumbs up

Great write-up!
__________________
SuncoastParts.com
Looking for the latest Genuine Porsche Parts and Accessories at wholesale prices?

Visit us at http://www.SuncoastParts.com
Call us at: 877-923-1700
Email us at: Parts@SuncoastParts.com

Follow us to stay connected:
Facebook
Twitter
Reply With Quote
  #5
Old 09-20-2010, 09:01 AM
roxboxxx's Avatar
Registered User

Join Date: Mar 2009
Location: NJ
Posts: 926
Rep Power: 58
roxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant future
Quote:
Originally Posted by suncoastric View Post
Great write-up!

BTW - You guys really delivered for me. I saw the weather was going to be nice so I called late on Thursday to see if you can overnight the stuff. You did and even threw in a few extra washers. My only regret is that I don't live closer to you guys.

Big ups to Suncoast !

(Now if I could only get you guys to sell me side-skirts for half price )
__________________
Everything I ever did to my pepa in one thread: http://www.6speedonline.com/forums/c...ervations.html
Reply With Quote
  #6
Old 09-20-2010, 04:53 PM
Jace's Avatar
Registered User

Join Date: May 2008
Location: Colorado
Posts: 1,712
Rep Power: 80
Jace is a glorious beacon of lightJace is a glorious beacon of lightJace is a glorious beacon of lightJace is a glorious beacon of lightJace is a glorious beacon of lightJace is a glorious beacon of light
SothebysColoradoRealtor Jason Kloss
Hoping suncoast is going to
Send me some of the new cayenne line up posters like they did with the 2008 refresh.
Let me know maybe...? ;-) PM thank you!
__________________
2011 Cayenne Turbo Meteor Grey Metallic with Cream Umber Interior
2008 Cayenne GTS Silver with Black Interior
Reply With Quote
  #7
Old 09-20-2010, 05:34 PM
bbywu's Avatar
Administrator

Join Date: Jan 2007
Location: OR Room 5
Posts: 10,739
Rep Power: 1002
bbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond repute
Great write up.

I would suugest using a hex bit rather than a Torx bit to remove the soft aluminum drain plug.

The drain plug is a metric hex bit. Using a proper bit (instead of an Allen key or Torx bit) will prevent stripping the plug.

Last edited by bbywu; 09-20-2010 at 05:37 PM.
Reply With Quote
  #8
Old 09-20-2010, 06:44 PM
porschespeeddemon's Avatar
Registered User

Join Date: May 2005
Location: Colorado
Age: 30
Posts: 1,304
Rep Power: 103
porschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond reputeporschespeeddemon has a reputation beyond repute
Send a message via Yahoo to porschespeeddemon
Quote:
Originally Posted by bbywu View Post
Great write up.

I would suugest using a hex bit rather than a Torx bit to remove the soft aluminum drain plug.

The drain plug is a metric hex bit. Using a proper bit (instead of an Allen key or Torx bit) will prevent stripping the plug.
Correct, 8mm Allen bit.
__________________
2004 Cayenne Turbo- Titanium/Black
Reply With Quote
  #9
Old 09-20-2010, 07:05 PM
Bigbuzuki's Avatar
Registered User

Join Date: Jun 2010
Location: Australia
Posts: 186
Rep Power: 12
Bigbuzuki will become famous soon enough
Good job Roxboxxx. Always enjoy reading about your projects.
__________________
2003 Cayenne Turbo
Reply With Quote
  #10
Old 09-20-2010, 07:38 PM
bbywu's Avatar
Administrator

Join Date: Jan 2007
Location: OR Room 5
Posts: 10,739
Rep Power: 1002
bbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond reputebbywu has a reputation beyond repute
Quote:
Originally Posted by porschespeeddemon View Post
Correct, 8mm Allen bit.
Consequences of using the wrong tool for the job:
Attached Thumbnails
Click image for larger version

Name:	photo.jpg
Views:	77
Size:	229.7 KB
ID:	133406   Click image for larger version

Name:	photo1.jpg
Views:	75
Size:	208.7 KB
ID:	133407
Reply With Quote
  #11
Old 09-20-2010, 09:48 PM
roxboxxx's Avatar
Registered User

Join Date: Mar 2009
Location: NJ
Posts: 926
Rep Power: 58
roxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant future
Quote:
Originally Posted by bbywu View Post
Great write up.

I would suugest using a hex bit rather than a Torx bit to remove the soft aluminum drain plug.

The drain plug is a metric hex bit. Using a proper bit (instead of an Allen key or Torx bit) will prevent stripping the plug.
Actually I have the hex, Porsche told me torx and 2 write ups on renntech said the same. When you look in the hole you can see the extra torx slots.
Def torx in my case
__________________
Everything I ever did to my pepa in one thread: http://www.6speedonline.com/forums/c...ervations.html
Reply With Quote
  #12
Old 04-23-2011, 10:54 AM
Registered User

Join Date: Apr 2011
Location: bond1577@gmail.com
Posts: 1
Rep Power: 0
helder1577 is on a distinguished road
oil change

Thanks alot for the detailed post. Im planning on changeing my oil next week for my 2004 cayenne. I have a few questions on your pics, what is the big round metal piece on the pic and do i need that tool? I also tried looking to buy new oil plugs and not sure if im buying the correct ones. I would appreciate any help. Thanks again.
Reply With Quote
  #13
Old 04-23-2011, 04:05 PM
Registered User

Join Date: Oct 2010
Posts: 216
Rep Power: 12
Markenstein3D is on a distinguished road
good write up - and nice break job!
Reply With Quote
  #14
Old 04-23-2011, 10:29 PM
Registered User

Join Date: Mar 2011
Location: San Diego
Posts: 46
Rep Power: 5
taddyangle is on a distinguished road
You can buy the plug from pelican. You can buy just the washers and/or plugs. I buy usually buy 4 washers and 2 plugs at a time. You should always change the washers every oil change. I change the plug every other oil change.
Reply With Quote
  #15
Old 04-25-2011, 08:06 PM
roxboxxx's Avatar
Registered User

Join Date: Mar 2009
Location: NJ
Posts: 926
Rep Power: 58
roxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant futureroxboxxx has a brilliant future
Quote:
Originally Posted by helder1577 View Post
Thanks alot for the detailed post. Im planning on changeing my oil next week for my 2004 cayenne. I have a few questions on your pics, what is the big round metal piece on the pic and do i need that tool? I also tried looking to buy new oil plugs and not sure if im buying the correct ones. I would appreciate any help. Thanks again.
The big round tool is needed to take off the oil filter housing. I bought mine from Suncoast porsche - believe it was $20. I also bought the oil pan plugs and washers from them. Overall, these tools are cheap and Suncoast is always great with their delivery.

Do not try to change ur oil without this tool and without new drain plugs! The plugs strip and you will be stuck if you do not have an extra handy.
__________________
Everything I ever did to my pepa in one thread: http://www.6speedonline.com/forums/c...ervations.html
Reply With Quote
