Which point is used for connect positive line(green color line in below link image) of led drl ring headlight on your Porsche? lead fuse box or any other point?
Also when led ring turn on? at start(ACC on) engine or with fog lamp?
Mine is a 997.1, but converted to .2 DRL lights, which had been configured by my workshop as followed:
0 - Engine start (lights switch off) = DRL On (the tube light in the middle)
1 - Lights switch to "Park Light" = DRL + Park light on
2 - Lights switch to "Low Beam" = DRL + Park + Low Beam
X - Lights switch to "Front Fog" = does NOT do anything (.2 don't have front fog lights).
The green wire for the "Ring" is tapped into the wire going to the "Park Light" (which can be accessed from inside the trunk to the bumper, for my car).
I ordered the black version, but silver version arrived instead. It always happen, right???!!
But since many of you are interested in seeing more pics with these lights on a real car, here's how they look on my black car without doing the transplant and connection.
Still waiting for the black ones, and I may get these connected in the mean time if I get too bored over this long weekend. Stay tuned!
and one for BEFORE and AFTER
Should totally rock just one and one... BMW Motorcycle owners would feel right at home.
2a - relocate (A) HID and (B) ballast from original lights to new lights - Easy
2b - relocate the (C) levelling motors from original lights to new lights - Easy, BUT, (D) pay attention to the "ball joint" tip when removing / inserting.
3- installing to the car. The rubber seal on the new lights is thicker than those on the original. It pushes the light forward a bit and I couldn't get it "locked". The trick was to (E) slide the mounting bracket forward by a little then the light will in place and locked properly.
Simon
You wrote motor removal and replacement was so easy but I don't thins so. I think this works is not easy.
Original motor and fake motor of aftermarket headlight(shipping clip) removal is easy but replacement is really hard to me.
Because original motor is a little shorter than fake motor of aftermarket headlight.
Therefore prominence-end of the original motor is not reach to clip of aftermarket headlight.
I tried several hour but I can't install still.
Please see attached image.
How can you fix this problem?
Last edited by hitman22; Sep 21, 2015 at 01:05 PM.
In the photo below, there are 2 nuts (circle in yellow) for adjusting the height and position of the light beam. You might need to adjust these two nuts in order to bring the mounting point close enough to you to mount the motor.
I forgot which direction is which but the headlights should come with a photo-instruction showing the direction.
Please note that this will make your light beam position to be completely out of place, so you will need to re-adjust the beam position so that the light aims properly and not blinding other people.
Simon, can you comment on how bright the light output is on the headlights at night? I know some aftermarket projectors have very poor output and beam pattern.
These lights reuse the stock HID kit. So there's no difference in the brightness output, and the beam pattern looks fine to me.
Originally Posted by PrecisionPorsch
Simon, can you comment on how bright the light output is on the headlights at night? I know some aftermarket projectors have very poor output and beam pattern.
)
